CCD Camera Board Model G-523S
Discription: Color CCD Camera Board
·1/3 inch Sony CCD
·520TV Lines,0.3LUX/F1.2
·38X38mm
·Single layer PCB Board
Camera Type
Color Board Camera
Image Sensor
1/3 Inch SONY SuperHAD CCD
Effective Pixels
PAL:752(H) x582(V) 440K
NTSC:768(H) x494(V) 380K
Sensing Area
4.9mm x 3.7mm
Signal System
PAL /NTSC
Horizontal Resolution
520TV Lines
Min. Illumination
0.3 Lux/F1.2
Lens Mount
Board lens mount (optional CS lens Mount)
S/N Ratio
More Than 48dB (AGC Off)
Electronic Shutter
1/50(1/60) ~ 1/10,000 Sec.
White Balance
Auto
AGC
Auto
I/O Connector
4 Pin Terminal(Power , Video ,GND)
Video Output Level
1.0 Vp-p (75 Ohms, composite)
Supplied Voltage
DC12V Voltage
Power Consumption
Less than 130mA
Dimensions
38 x38mm/ Single layer PCB
Weight
Approx. 20g
