Sony CCD Camera Board Model G-422S
Discription: Color Sony CCD Camera Board
·1/4 inch Sony CCD
·420 TVL,0.8 LUX/F1.2
·32 x 32mm
·Single layer PCB Board
Camera Type
Color Board Camera
Image Sensor
1/4 Inch SONY SuperHAD CCD
Effective Pixels
PAL:500(H) x 582(V) 290K
NTSC:510(H) x 492(V) 250K
Sensing Area
3.6mm x 2.7mm
Signal System
PAL /NTSC
Horizontal Resolution
420 TV Lines
Min. Illumination
0.8 Lux/F1.2
Lens Mount
Board lens mount (optional CS lens Mount)
S/N Ratio
More Than 48dB (AGC Off)
Electronic Shutter
1/50(1/60) ~ 1/10,000 Sec.
White Balance
Auto
AGC
Auto
I/O Connector
4 Pin Terminal(Power , Video ,GND)
Video Output Level
1.0 Vp-p (75 Ohms, composite)
Supplied Voltage
DC12V Voltage
Power Consumption
Less than 130mA
Dimensions
32 x32mm/ Single layer PCB
Weight
Approx. 15g
